It is equipped with high precision constant temperature water bath, pycnometer, beaker and thermometer, it is suitable for the test of density and relative density of various bitumen materials.
This tester has the advantages of advanced design, high temperature control precision and good constant temperature effect. It is the ideal instrument for the bitumen production enterprises, construction units, research institutes, colleges and universities and other units to test the density and relative density of various bitumen materials.
In addition to being used as a special instrument for bitumen density and relative density test, since it is a multi-functional circulating constant temperature water bath instrument, it can not only provide a constant temperature bath for various of high and low temperature test; the circulating system of the constant temperature water bath also can be used in the other closed circulation systems, and suitable for multi-purpose use in relevant laboratories.
Power supply |
AC(220±10%)V, 50Hz |
Maximum power consumption |
1100W |
Pycnometer |
20ml~30ml |
Bath volume |
10L |
Temperature range |
(-10~95)ºC |
Temperature precision |
±0.1ºC |
Water circulating rate |
≥4L/min |
Ambient temperature |
-10ºC~+30ºC |
Relative humidity |
≤85% |
Dimension |
540mm×390mm×420mm |
