Portable Multiparameter Water Quality Meter




  • بررسی و خرید
  • Description :

    Multiparameter portable water quality meter contains the 8 measurement modes. The meter is used for measuring the pH, ORP, Ion concentration, Conductivity, TDS, Salinity, Resistivity and Dissolved Oxygen of the liquids.

    pH Mode:

    • Portable multiparameter water quality meter is equipped with a large backlit LCD display.
    • 1 to 5 points push-button calibration with auto-buffer recognition.
    • Selectable pH buffer standard (USA/NIST/DIN) or using the custom calibration solutions.
    • Automatic electrode slope display helps user decide whether to replace sensor.
    ORP Mode:
    • Single point offset calibration allows adjusting the displayed value to a known standard.
    • Relative and absolute millivolts measurement modes provide accurate ORP readings.
    Ion Mode:
    • 2 to 5 points calibration including the eight concentration calibration points can be selected.
    • Automatically recognize ion selective electrodes, does not need to specify type of ion.
    • Direct ion concentration readout simplifies the elaborate measurement process.
    • Selectable multiple concentration units include the ppm, mg/L and mol/L.
    Conductivity/TDS/Salinity/Resistivity Mode:
    • 1 to 5 points push-button calibration with automatic calibration solution recognition.
    • Selectable cell constant (0.1/1/10), normalization temperature (20/25°C), TDS conversion factor,

    seawater and practical salinity measurement modes.
    • Linear or pure water compensation improves measurement accuracy of meter.
    Dissolved Oxygen Mode:
    • 1 or 2 points calibration using the air-saturated water and zero oxygen solution.
    • Manual salinity and barometric pressure compensation improve the measurement accuracy.
    Other Features:
    • Automatic Temperature Compensation provides accurate reading over the entire range.
    • Calibration Due Reminder prompts user to calibrate the meter regularly.
    • Stability indicator automatically shows current measurement status.
    • Auto-Hold function freezes stable measured value for easy viewing and recording.
    • Manual temperature calibration corrects temperature deviation.
    • Selectable temperature unit (°C or °F) meets different application requirements.
    • Automatic electrode diagnosis shows zero point offset and slope of the electrode.
    • Help message as a operational guide that helps you quickly begin using the meter.
    • System menu allows setting the 15 parameters, including the number of calibration points,
      resolution, stability condition, measurement unit, etc.
    • Reset feature automatically resumes all parameters back to factory default settings.
    • Expanded memory stores and recalls up to 500 readings.
    • Built-in real-time clock stamps stored data to meet GLP standard.
    • Stored data can be transferred into computer by USB communication interface.
    • Multi-mode power scheme (battery, power adapter, computer's USB port) ensures that use the meter smoothly.

    specification :

    pH



    Range



    -2.000~20.000pH

    Accuracy



    ±0.002pH

    Resolution



    0.1, 0.01, 0.001pH, Selectable

    Calibration Points



    1 to 5 points

    Calibration Solutions



    USA, NIST, DIN or User-defined

    Temperature Compensation



    0~100°C, 32~212°F

    Compensation Mode



    Manual or Automatic

    mV



    Range



    -1999.9~1999.9mV

    Accuracy



    ±0.2mV

    Resolution



    0.1, 1mV, Selectable

    Calibration Points



    1 point (Only for Relative mV mode)

    Calibration Range



    ±200mV

    Ion



    Range



    0.001~19999ppm, mg/L, mol/L (Refer to the range of ISE)

    Accuracy



    ±0.5% F.S (Monovalent), ±1% F.S (Divalent)

    Resolution



    0.001, 0.01, 0.1, 1

    Calibration Points



    2 to 5 points

    Calibration Solutions



    0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000ppm, mg/L, mol/L

    Temperature Compensation



    0~100°C, 32~212°F

    Compensation Mode



    Manual or Automatic

    Conductivity



    Range



    0~20.00, 200.0, 2000µS/cm, 20.00, 200.0mS/cm

    Accuracy



    ±0.5% F.S

    Calibration Points



    1 to 5 points

    Calibration Solutions



    10µS/cm, 84µS/cm, 1413µS/cm, 12.88mS/cm, 111.8mS/cm

    Temperature Compensation



    0~100°C, 32~212°F, Manual or Automatic

    Temperature Coefficient



    0.0~10.0%/°C

    Compensation Modes



    Linear or Pure Water

    Cell Constant



    K=0.1, 1, 10 or User-defined

    Normalization Temperature



    20°C or 25°C

    TDS



    Range



    0~100ppt (Max. 200ppt, depending on factor setting)

    Accuracy



    ±1% F.S

    TDS Factor



    0.1~1.0 (Default 0.5)

    Salinity



    Range



    0~10ppt (Max. 80ppt)

    Accuracy



    ±1% F.S

    Measurement Modes



    Seawater or Practical Salinity

    Resistivity



    Range



    0~100MΩ

    Accuracy



    ±1% F.S

    Resolution



    0.01, 0.1, 1

    Dissolved Oxygen



    Range



    0.00~20.00mg/L (or ppm)

    Accuracy



    ±0.2mg/L

    Resolution



    0.01mg/L

    Calibration Points



    1 or 2 points

    Temperature Compensation



    0~50°C, 32~122°F, Automatic

    Pressure Correction



    60.0~112.5kPa, 450~850mmHg

    Salinity Correction



    0~50g/L

    % Saturation of Oxygen



    Range



    0.0~200.0%

    Accuracy



    ±2.0%

    Resolution



    0.1, 1%

    Temperature



    Range



    0~105°C, 32~221°F

    Accuracy



    ±0.5°C, ±0.9°F

    Resolution



    0.1°C

    Calibration Points



    1 point

    Calibration Range



    Measured value ±10°C

    Others



    Hold Function



    Manual or Automatic

    Stability Conditions



    Low or High

    Calibration Due



    0 to 31 days

    Power Off



    Manual or Automatic (10, 20, 30 minutes)

    Reset Function



    Yes

    Memory



    Stores up to 500 data sets

    Output



    USB Communication Interface

    Connector



    BNC, 6-pin Mini Plug

    Power Requirements



    3×1.5V "AA" Batteries

    Battery Life



    Approximately 150 hours (Turn off the backlit)

    Dimensions



    170(L)×85(W)×30(H)mm

    Weight



    300g
