Online Dissolved Oxygen Controller ST 460
Economical online dissolved oxygen controller, 1 or 2 points calibration, 4 to 20mA signal output. The meter is used for monitoring the dissolved oxygen concentration and percentage saturation in the water.
Features:
• Economical online dissolved oxygen controller is equipped with a polarographic sensor.
• 1 or 2 points calibration using the air-saturated water and zero oxygen solution.
• Manual salinity and barometric pressure compensation improve the measurement accuracy.
• Automatic Temperature Compensation ensures accurate reading over the entire range.
• Low and high alarm limits can be set by user and automatically activate an external device.
• 4 to 20mA output signal meets industry standard.
• System menu allows setting the 10 parameters, including the number of calibration points,
measurement unit, alarm limits, hysteresis value, etc.
• Reset feature automatically resumes all settings back to factory default options.
Specification :
| Range | 0.0~20.0mg/L (or ppm) |
| Accuracy | ±0.5mg/L |
| Resolution | 0.1mg/L |
| % Saturation of Oxygen | |
| Range | 0.0~200.0% |
| Accuracy | ±10% F.S |
| Resolution | 0.1% |
| Communication | |
| Signal Output | 4~20mA |
| Load | Max. 500Ω |
| Low and high alarm limits | 1.00~18.00mg/L, Selectable |
| Communication Interface | RS485 |
| Connection Terminals | Detachable screw terminals |
| Others | |
| Temperature Compensation | 0~40°C, 32~104°F |
| Compensation Mode | Automatic |
| Barometric Pressure Correction | 60.0~112.5kPa, 450~850mmHg |
| Salinity Correction | 0~35g/L |
| Environmental Conditions | 0~60°C, 32~140°F |
| Power Requirements | DC24V |
| Dimensions | 96(L)×96(W)×75(H)mm |
| Weight | 350g |
Precise Dissolved Oxygen Measurement for Water Quality and Process Control
Online Dissolved Oxygen Controller ST 460 Ensure accurate, real-time monitoring of dissolved oxygen (DO) levels with our versatile range of dissolved oxygen meters—essential tools for environmental testing, wastewater treatment, aquaculture, biotechnology, and laboratory research. Whether you’re assessing aquatic ecosystem health, optimizing aeration in treatment plants, or controlling fermentation processes, our DO meters deliver reliable, lab-grade results in the field or on the bench.
Advanced Technology for Consistent Accuracy
Our dissolved oxygen meters utilize either electrochemical (galvanic/polarographic) or optical (luminescence-based) sensor technology—both offering high sensitivity, fast response, and long-term stability. Optical sensors require no membrane replacement or electrolyte refills, while electrochemical probes provide proven performance at an accessible price point.
- Wide DO Range – Measures from 0.00 to 20.00 mg/L (ppm) or 0–200% saturation, suitable for freshwater, seawater, and process streams.
- Automatic Temperature & Salinity Compensation – Ensures accurate readings across varying environmental conditions.
- Barometric Pressure Correction – Built-in or manual pressure adjustment for altitude and weather-related accuracy.
- Rugged, Portable Designs – IP67-rated handheld models for field use; benchtop versions for lab precision.
- Data Logging & Connectivity – Store hundreds of readings with timestamps; export via USB or Bluetooth for reporting.
- Low Maintenance & Calibration Alerts – Intuitive prompts for zero-point or saturation calibration to maintain compliance.
Trusted for Critical Applications
From regulatory compliance (EPA, ISO 5814) to protecting fish stocks in aquaculture, accurate DO measurement is non-negotiable. Our meters support GLP/GMP standards, feature durable construction, and are designed for minimal drift—so you can trust your data, run after run.
Whether you need a simple spot-check tool or a fully traceable monitoring system, our dissolved oxygen meters offer the precision, durability, and ease of use your work demands.
Make every measurement count—with confidence in your water’s most vital parameter.
